TAPPER Hardware Description

In this article, you will find the details about the TAPPER hardware configuration.

Basic Parameters

Electrical
Minimal supply voltage	10 V
Maximum supply voltage	30 V
Typical power consumption	1.4 W
Maximum power consumption	2.5 W
Inputs
Terminal block nominal cross section	1.5 mm²
DC power Jack	1.3x3.8 mm
Outputs
RGB LED	355 mcd, 710 mcd, 140 mcd
Buzzer	80 dBA / 2.7 kHz
Physical
Enclosure dimensions	155x84x21.3 mm
Enclosure material	ASA+PC (UL 94 V-0)
Enclosure protection class	IP40
Enclosure colour	traffic white RAL 9016
Operation temperature	-20 °C to +60 °C
